要想实现我们上一节中提到的：

• 需要在重试以及断路中加一些日志，便于日后的优化
• 需要定义重试的 Exception，并且与断路器相结合，将非 2xx 的响应码也封装成特定的异常
• 需要在断路器相关的 Operator 中增加类似于 FeignClient 中的负载均衡的数据更新，使得负载均衡更加智能

我们需要将 resilience4j 本身提供的粘合库做一些改造，其实主要就是对 resilience4j 实现的 project reactor 的 Operator 进行改造。

关于断路器的改造

首先，WebClient 的返回对象只可能是 ClientResponse 类型，所以我们这里改造出来的 Operator 不必带上形参，只需要针对 ClientResponse 即可，即：

public class ClientResponseCircuitBreakerOperator implements UnaryOperator<Publisher<ClientResponse>> {    ...}

在原有的断路器逻辑中，我们需要加入针对 GET 方法以及之前定义的可以重试的路径匹配配置可以重试的逻辑，这需要我们拿到原有请求的 URL 信息。但是 ClientResponse 中并没有暴露这些信息的接口，其默认实现 DefaultClientResponse（我们只要没有自己给 WebClient 加入特殊的改造逻辑，实现都是 DefaultClientResponse） 中的 request()方法可以获取请求 HttpRequest，其中包含 url 信息。但是这个类还有方法都是 package-private 的，我们需要反射出来：

ClientResponseCircuitBreakerSubscriber

private static final Class<?> aClass;private static final Method request;static {    try {        aClass = Class.forName("org.springframework.web.reactive.function.client.DefaultClientResponse");        request = ReflectionUtils.findMethod(aClass, "request");        request.setAccessible(true);    } catch (Exception e) {        throw new RuntimeException(e);    }}

之后，在获取到 ClientResponse 之后记录断路器的逻辑中，需要加入上面提到的关于重试的改造，以及负载均衡器的记录：

ClientResponseCircuitBreakerSubscriber

protected void hookOnNext(ClientResponse clientResponse) {    if (!isDisposed()) {        if (singleProducer && successSignaled.compareAndSet(false, true)) {            int rawStatusCode = clientResponse.rawStatusCode();            HttpStatus httpStatus = HttpStatus.resolve(rawStatusCode);            try {                HttpRequest httpRequest = (HttpRequest) request.invoke(clientResponse);                //判断方法是否为 GET，以及是否在可重试路径配置中，从而得出是否可以重试                if (httpRequest.getMethod() != HttpMethod.GET && !webClientProperties.retryablePathsMatch(httpRequest.getURI().getPath())) {                    //如果不能重试，则直接返回结果                    circuitBreaker.onResult(circuitBreaker.getCurrentTimestamp() - start, circuitBreaker.getTimestampUnit(), clientResponse);                } else {                    if (httpStatus != null && httpStatus.is2xxSuccessful()) {                        //如果成功，则直接返回结果                        circuitBreaker.onResult(circuitBreaker.getCurrentTimestamp() - start, circuitBreaker.getTimestampUnit(), clientResponse);                    } else {                        /**                         * 如果异常，参考 DefaultClientResponse 的代码进行异常封装                         * @see org.springframework.web.reactive.function.client.DefaultClientResponse#createException                         */                        Exception exception;                        if (httpStatus != null) {                            exception = WebClientResponseException.create(rawStatusCode, httpStatus.getReasonPhrase(), clientResponse.headers().asHttpHeaders(), EMPTY, null, null);                        } else {                            exception = new UnknownHttpStatusCodeException(rawStatusCode, clientResponse.headers().asHttpHeaders(), EMPTY, null, null);                        }                        circuitBreaker.onError(circuitBreaker.getCurrentTimestamp() - start, circuitBreaker.getTimestampUnit(), exception);                        downstreamSubscriber.onError(exception);                        return;                    }                }            } catch (Exception e) {                log.fatal("judge request method in circuit breaker error! the resilience4j feature would not be enabled: {}", e.getMessage(), e);                circuitBreaker.onResult(circuitBreaker.getCurrentTimestamp() - start, circuitBreaker.getTimestampUnit(), clientResponse);            }        }        eventWasEmitted.set(true);        downstreamSubscriber.onNext(clientResponse);    }}

同样的，在原有的完成，取消还有失败的记录逻辑中，也加上记录负载均衡数据：

ClientResponseCircuitBreakerSubscriber

@Overrideprotected void hookOnComplete() {    if (successSignaled.compareAndSet(false, true)) {        serviceInstanceMetrics.recordServiceInstanceCalled(serviceInstance, true);        circuitBreaker.onSuccess(circuitBreaker.getCurrentTimestamp() - start, circuitBreaker.getTimestampUnit());    }    downstreamSubscriber.onComplete();}@Overridepublic void hookOnCancel() {    if (!successSignaled.get()) {        serviceInstanceMetrics.recordServiceInstanceCalled(serviceInstance, true);        if (eventWasEmitted.get()) {            circuitBreaker.onSuccess(circuitBreaker.getCurrentTimestamp() - start, circuitBreaker.getTimestampUnit());        } else {            circuitBreaker.releasePermission();        }    }}@Overrideprotected void hookOnError(Throwable e) {    serviceInstanceMetrics.recordServiceInstanceCalled(serviceInstance, false);    circuitBreaker.onError(circuitBreaker.getCurrentTimestamp() - start, circuitBreaker.getTimestampUnit(), e);    downstreamSubscriber.onError(e);}

粘合 WebClient 与 resilience4j 的同时覆盖重试逻辑

由于前面的断路器中，我们针对可以重试的非 2XX 响应封装成为 WebClientResponseException。所以在重试器中，我们需要加上针对这个异常的重试。

同时，需要将重试器放在负载均衡器之前，因为每次重试，都要从负载均衡器中获取一个新的实例。同时，断路器需要放在负载均衡器之后，因为只有在这个之后，才能获取到本次调用的实例，我们的的断路器是针对实例方法级别的：

WebClientDefaultConfiguration.java

@Beanpublic WebClient getWebClient(        ReactorLoadBalancerExchangeFilterFunction lbFunction,        WebClientConfigurationProperties webClientConfigurationProperties,        Environment environment,        RetryRegistry retryRegistry,        CircuitBreakerRegistry circuitBreakerRegistry,        ServiceInstanceMetrics serviceInstanceMetrics) {    String name = environment.getProperty(WebClientNamedContextFactory.PROPERTY_NAME);    Map<String, WebClientConfigurationProperties.WebClientProperties> configs = webClientConfigurationProperties.getConfigs();    if (configs == null || configs.size() == 0) {        throw new BeanCreationException("Failed to create webClient, please provide configurations under namespace: webclient.configs");    }    WebClientConfigurationProperties.WebClientProperties webClientProperties = configs.get(name);    if (webClientProperties == null) {        throw new BeanCreationException("Failed to create webClient, please provide configurations under namespace: webclient.configs." + name);    }    String serviceName = webClientProperties.getServiceName();    //如果没填写微服务名称，就使用配置 key 作为微服务名称    if (StringUtils.isBlank(serviceName)) {        serviceName = name;    }    String baseUrl = webClientProperties.getBaseUrl();    //如果没填写 baseUrl，就使用微服务名称填充    if (StringUtils.isBlank(baseUrl)) {        baseUrl = "http://" + serviceName;    }    Retry retry = null;    try {        retry = retryRegistry.retry(serviceName, serviceName);    } catch (ConfigurationNotFoundException e) {        retry = retryRegistry.retry(serviceName);    }    //覆盖其中的异常判断    retry = Retry.of(serviceName, RetryConfig.from(retry.getRetryConfig()).retryOnException(throwable -> {        //WebClientResponseException 会重试，因为在这里能 catch 的 WebClientResponseException 只对可以重试的请求封装了 WebClientResponseException        //参考 ClientResponseCircuitBreakerSubscriber 的代码        if (throwable instanceof WebClientResponseException) {            log.info("should retry on {}", throwable.toString());            return true;        }        //断路器异常重试，因为请求没有发出去        if (throwable instanceof CallNotPermittedException) {            log.info("should retry on {}", throwable.toString());            return true;        }        if (throwable instanceof WebClientRequestException) {            WebClientRequestException webClientRequestException = (WebClientRequestException) throwable;            HttpMethod method = webClientRequestException.getMethod();            URI uri = webClientRequestException.getUri();            //判断是否为响应超时，响应超时代表请求已经发出去了，对于非 GET 并且没有标注可以重试的请求则不能重试            boolean isResponseTimeout = false;            Throwable cause = throwable.getCause();            //netty 的读取超时一般是 ReadTimeoutException            if (cause instanceof ReadTimeoutException) {                log.info("Cause is a ReadTimeoutException which indicates it is a response time out");                isResponseTimeout = true;            } else {                //对于其他一些框架，使用了 java 底层 nio 的一般是 SocketTimeoutException，message 为 read time out                //还有一些其他异常，但是 message 都会有 read time out 字段，所以通过 message 判断                String message = throwable.getMessage();                if (StringUtils.isNotBlank(message) && StringUtils.containsIgnoreCase(message.replace(" ", ""), "readtimeout")) {                    log.info("Throwable message contains readtimeout which indicates it is a response time out");                    isResponseTimeout = true;                }            }            //如果请求是 GET 或者标注了重试，则直接判断可以重试            if (method == HttpMethod.GET || webClientProperties.retryablePathsMatch(uri.getPath())) {                log.info("should retry on {}-{}, {}", method, uri, throwable.toString());                return true;            } else {                //否则，只针对请求还没有发出去的异常进行重试                if (isResponseTimeout) {                    log.info("should not retry on {}-{}, {}", method, uri, throwable.toString());                } else {                    log.info("should retry on {}-{}, {}", method, uri, throwable.toString());                    return true;                }            }        }        return false;    }).build());    HttpClient httpClient = HttpClient            .create()            .option(ChannelOption.CONNECT_TIMEOUT_MILLIS, (int) webClientProperties.getConnectTimeout().toMillis())            .doOnConnected(connection ->                    connection                            .addHandlerLast(new ReadTimeoutHandler((int) webClientProperties.getResponseTimeout().toSeconds()))                            .addHandlerLast(new WriteTimeoutHandler((int) webClientProperties.getResponseTimeout().toSeconds()))            );    Retry finalRetry = retry;    String finalServiceName = serviceName;    return WebClient.builder()            .exchangeStrategies(ExchangeStrategies.builder()            .codecs(configurer -> configurer                    .defaultCodecs()                    //最大 body 占用 16m 内存                    .maxInMemorySize(16 * 1024 * 1024))            .build())            .clientConnector(new ReactorClientHttpConnector(httpClient))            //Retry在负载均衡前            .filter((clientRequest, exchangeFunction) -> {                return exchangeFunction                        .exchange(clientRequest)                        .transform(ClientResponseRetryOperator.of(finalRetry));            })            //负载均衡器，改写url            .filter(lbFunction)            //实例级别的断路器需要在负载均衡获取真正地址之后            .filter((clientRequest, exchangeFunction) -> {                ServiceInstance serviceInstance = getServiceInstance(clientRequest);                serviceInstanceMetrics.recordServiceInstanceCall(serviceInstance);                CircuitBreaker circuitBreaker;                //这时候的url是经过负载均衡器的，是实例的url                //需要注意的一点是，使用异步 client 的时候，最好不要带路径参数，否则这里的断路器效果不好                //断路器是每个实例每个路径一个断路器                String instancId = clientRequest.url().getHost() + ":" + clientRequest.url().getPort() + clientRequest.url().getPath();                try {                    //使用实例id新建或者获取现有的CircuitBreaker,使用serviceName获取配置                    circuitBreaker = circuitBreakerRegistry.circuitBreaker(instancId, finalServiceName);                } catch (ConfigurationNotFoundException e) {                    circuitBreaker = circuitBreakerRegistry.circuitBreaker(instancId);                }                log.info("webclient circuit breaker [{}-{}] status: {}, data: {}", finalServiceName, instancId, circuitBreaker.getState(), JSON.toJSONString(circuitBreaker.getMetrics()));                return exchangeFunction.exchange(clientRequest).transform(ClientResponseCircuitBreakerOperator.of(circuitBreaker, serviceInstance, serviceInstanceMetrics, webClientProperties));            }).baseUrl(baseUrl)            .build();}private ServiceInstance getServiceInstance(ClientRequest clientRequest) {    URI url = clientRequest.url();    DefaultServiceInstance defaultServiceInstance = new DefaultServiceInstance();    defaultServiceInstance.setHost(url.getHost());    defaultServiceInstance.setPort(url.getPort());    return defaultServiceInstance;}

这样，我们就实现了我们封装的基于配置的 WebClient
