上一节我们通过单元测试验证了重试的正确性，这一节我们来验证我们线程隔离的正确性，主要包括：

1. 验证配置正确加载：即我们在 Spring 配置（例如 application.yml）中的加入的 Resilience4j 的配置被正确加载应用了。
2. 相同微服务调用不同实例的时候，使用的是不同的线程（池）。

验证配置正确加载

与之前验证重试类似，我们可以定义不同的 FeignClient，之后检查 resilience4j 加载的线程隔离配置来验证线程隔离配置的正确加载。

并且，与重试配置不同的是，通过系列前面的源码分析，我们知道 spring-cloud-openfeign 的 FeignClient 其实是懒加载的。所以我们实现的线程隔离也是懒加载的，需要先调用，之后才会初始化线程池。所以这里我们需要先进行调用之后，再验证线程池配置。

首先定义两个 FeignClient，微服务分别是 testService1 和 testService2，contextId 分别是 testService1Client 和 testService2Client

@FeignClient(name = "testService1", contextId = "testService1Client")public interface TestService1Client {    @GetMapping("/anything")    HttpBinAnythingResponse anything();}@FeignClient(name = "testService2", contextId = "testService2Client")    public interface TestService2Client {        @GetMapping("/anything")        HttpBinAnythingResponse anything();}

然后，我们增加 Spring 配置，并且给两个微服务都添加一个实例，使用 SpringExtension 编写单元测试类：

//SpringExtension也包含了 Mockito 相关的 Extension，所以 @Mock 等注解也生效了@ExtendWith(SpringExtension.class)@SpringBootTest(properties = {        //默认请求重试次数为 3        "resilience4j.retry.configs.default.maxAttempts=3",        // testService2Client 里面的所有方法请求重试次数为 2        "resilience4j.retry.configs.testService2Client.maxAttempts=2",        //默认线程池配置        "resilience4j.thread-pool-bulkhead.configs.default.coreThreadPoolSize=10",        "resilience4j.thread-pool-bulkhead.configs.default.maxThreadPoolSize=10",        "resilience4j.thread-pool-bulkhead.configs.default.queueCapacity=1" ,        //testService2Client 的线程池配置        "resilience4j.thread-pool-bulkhead.configs.testService2Client.coreThreadPoolSize=5",        "resilience4j.thread-pool-bulkhead.configs.testService2Client.maxThreadPoolSize=5",        "resilience4j.thread-pool-bulkhead.configs.testService2Client.queueCapacity=1",})@Log4j2public class OpenFeignClientTest {    @SpringBootApplication    @Configuration    public static class App {        @Bean        public DiscoveryClient discoveryClient() {            //模拟两个服务实例            ServiceInstance service1Instance1 = Mockito.spy(ServiceInstance.class);            ServiceInstance service2Instance2 = Mockito.spy(ServiceInstance.class);            Map<String, String> zone1 = Map.ofEntries(                    Map.entry("zone", "zone1")            );            when(service1Instance1.getMetadata()).thenReturn(zone1);            when(service1Instance1.getInstanceId()).thenReturn("service1Instance1");            when(service1Instance1.getHost()).thenReturn("www.httpbin.org");            when(service1Instance1.getPort()).thenReturn(80);            when(service2Instance2.getInstanceId()).thenReturn("service1Instance2");            when(service2Instance2.getHost()).thenReturn("httpbin.org");            when(service2Instance2.getPort()).thenReturn(80);            DiscoveryClient spy = Mockito.spy(DiscoveryClient.class);            Mockito.when(spy.getInstances("testService1"))                    .thenReturn(List.of(service1Instance1));            Mockito.when(spy.getInstances("testService2"))                    .thenReturn(List.of(service2Instance2));            return spy;        }    }}

编写测试代码，验证配置正确：

@Testpublic void testConfigureThreadPool() {    //防止断路器影响    circuitBreakerRegistry.getAllCircuitBreakers().asJava().forEach(CircuitBreaker::reset);    //调用下这两个 FeignClient 确保对应的 NamedContext 被初始化    testService1Client.anything();    testService2Client.anything();    //验证线程隔离的实际配置，符合我们的填入的配置    ThreadPoolBulkhead threadPoolBulkhead = threadPoolBulkheadRegistry.getAllBulkheads().asJava()            .stream().filter(t -> t.getName().contains("service1Instance1")).findFirst().get();    Assertions.assertEquals(threadPoolBulkhead.getBulkheadConfig().getCoreThreadPoolSize(), 10);    Assertions.assertEquals(threadPoolBulkhead.getBulkheadConfig().getMaxThreadPoolSize(), 10);    threadPoolBulkhead = threadPoolBulkheadRegistry.getAllBulkheads().asJava()            .stream().filter(t -> t.getName().contains("service1Instance2")).findFirst().get();    Assertions.assertEquals(threadPoolBulkhead.getBulkheadConfig().getCoreThreadPoolSize(), 5);    Assertions.assertEquals(threadPoolBulkhead.getBulkheadConfig().getMaxThreadPoolSize(), 5);}

相同微服务调用不同实例的时候，使用的是不同的线程（池）。

我们需要确保，最后调用（也就是发送 http 请求）的执行的线程池，必须是对应的 ThreadPoolBulkHead 中的线程池。这个需要我们对 ApacheHttpClient 做切面实现，添加注解 @EnableAspectJAutoProxy(proxyTargetClass = true)：

//SpringExtension也包含了 Mockito 相关的 Extension，所以 @Mock 等注解也生效了@ExtendWith(SpringExtension.class)@SpringBootTest(properties = {        //默认请求重试次数为 3        "resilience4j.retry.configs.default.maxAttempts=3",        // testService2Client 里面的所有方法请求重试次数为 2        "resilience4j.retry.configs.testService2Client.maxAttempts=2",        //默认线程池配置        "resilience4j.thread-pool-bulkhead.configs.default.coreThreadPoolSize=10",        "resilience4j.thread-pool-bulkhead.configs.default.maxThreadPoolSize=10",        "resilience4j.thread-pool-bulkhead.configs.default.queueCapacity=1" ,        //testService2Client 的线程池配置        "resilience4j.thread-pool-bulkhead.configs.testService2Client.coreThreadPoolSize=5",        "resilience4j.thread-pool-bulkhead.configs.testService2Client.maxThreadPoolSize=5",        "resilience4j.thread-pool-bulkhead.configs.testService2Client.queueCapacity=1",})@Log4j2public class OpenFeignClientTest {    @SpringBootApplication    @Configuration    @EnableAspectJAutoProxy(proxyTargetClass = true)    public static class App {        @Bean        public DiscoveryClient discoveryClient() {            //模拟两个服务实例            ServiceInstance service1Instance1 = Mockito.spy(ServiceInstance.class);            ServiceInstance service2Instance2 = Mockito.spy(ServiceInstance.class);            Map<String, String> zone1 = Map.ofEntries(                    Map.entry("zone", "zone1")            );            when(service1Instance1.getMetadata()).thenReturn(zone1);            when(service1Instance1.getInstanceId()).thenReturn("service1Instance1");            when(service1Instance1.getHost()).thenReturn("www.httpbin.org");            when(service1Instance1.getPort()).thenReturn(80);            when(service2Instance2.getInstanceId()).thenReturn("service1Instance2");            when(service2Instance2.getHost()).thenReturn("httpbin.org");            when(service2Instance2.getPort()).thenReturn(80);            DiscoveryClient spy = Mockito.spy(DiscoveryClient.class);            Mockito.when(spy.getInstances("testService1"))                    .thenReturn(List.of(service1Instance1));            Mockito.when(spy.getInstances("testService2"))                    .thenReturn(List.of(service2Instance2));            return spy;        }    }}

拦截 ApacheHttpClient 的 execute 方法，这样可以拿到真正负责 http 调用的线程池，将线程其放入请求的 Header：

@Aspectpublic static class ApacheHttpClientAop {    //在最后一步 ApacheHttpClient 切面    @Pointcut("execution(* com.github.jojotech.spring.cloud.webmvc.feign.ApacheHttpClient.execute(..))")    public void annotationPointcut() {    }    @Around("annotationPointcut()")    public Object around(ProceedingJoinPoint pjp) throws Throwable {        //设置 Header，不能通过 Feign 的 RequestInterceptor，因为我们要拿到最后调用 ApacheHttpClient 的线程上下文        Request request = (Request) pjp.getArgs()[0];        Field headers = ReflectionUtils.findField(Request.class, "headers");        ReflectionUtils.makeAccessible(headers);        Map<String, Collection<String>> map = (Map<String, Collection<String>>) ReflectionUtils.getField(headers, request);        HashMap<String, Collection<String>> stringCollectionHashMap = new HashMap<>(map);        stringCollectionHashMap.put(THREAD_ID_HEADER, List.of(String.valueOf(Thread.currentThread().getName())));        ReflectionUtils.setField(headers, request, stringCollectionHashMap);        return pjp.proceed();    }}

这样，我们就能拿到具体承载请求的线程的名称，从名称中可以看出他所处于的线程池（格式为“bulkhead-线程隔离名称-n”，例如 bulkhead-testService1Client:www.httpbin.org:80-1），接下来我们就来看下不同的实例是否用了不同的线程池进行调用：

@Testpublic void testDifferentThreadPoolForDifferentInstance() throws InterruptedException {    //防止断路器影响    circuitBreakerRegistry.getAllCircuitBreakers().asJava().forEach(CircuitBreaker::reset);    Set<String> threadIds = Sets.newConcurrentHashSet();    Thread[] threads = new Thread[100];    //循环100次    for (int i = 0; i < 100; i++) {        threads[i] = new Thread(() -> {            Span span = tracer.nextSpan();            try (Tracer.SpanInScope cleared = tracer.withSpanInScope(span)) {                HttpBinAnythingResponse response = testService1Client.anything();                //因为 anything 会返回我们发送的请求实体的所有内容，所以我们能获取到请求的线程名称 header                String threadId = response.getHeaders().get(THREAD_ID_HEADER);                threadIds.add(threadId);            }        });        threads[i].start();    }    for (int i = 0; i < 100; i++) {        threads[i].join();    }    //确认实例 testService1Client:httpbin.org:80 线程池的线程存在    Assertions.assertTrue(threadIds.stream().anyMatch(s -> s.contains("testService1Client:httpbin.org:80")));    //确认实例 testService1Client:httpbin.org:80 线程池的线程存在    Assertions.assertTrue(threadIds.stream().anyMatch(s -> s.contains("testService1Client:www.httpbin.org:80")));}

这样，我们就成功验证了，实例调用的线程池隔离。
